WTA – 2.4GHz Indoor Amplifiers

Industrial Grade Indoor 802.11b/g Amplifiers



WiFi Technologies 802.11b/g bi-directional amplifiers feature Active Power Control which monitors the amplifier's output power and automatically adjusts to provide maximum output power regardless of cable length. Consisting of a low-noise receive amplifier and a transmit power amplifier, these units offer significant improvement in operating range and performance. Amplifiers are compatible with spread spectrum wireless gear including IEEE 802.11b / 802.11g.

  • 802.11b and 802.11g Compatible
  • Active Power Control
  • Cast Aluminium Construction
  • Durable UV-Stable Finish
  • Transmit and Receive LEDs
  • RP-TNC connectors (eliminating the requirement for professional installation)



Model Maximum
Output
Receive
Gain
802.11b 802.11g Streaming
Media Ready
Dimensions
 WTA-2401RTGI-100 100 mW
(20 dBm)
15 dB nom.

Yes



117 x 66 x 43 (mm)
300g

 WTA-2401RTGI-250 250 mW
(24 dBm)
15 dB nom.

Yes


 WTA-2401RTGI-500 500 mW
(27 dBm)
15 dB nom. Yes
 WTA-2401RTGI-1000 1 W
(30 dBm)
15 dB nom. Yes
 WTA-2401RTGXI-500 500 mW
(27 dBm)
12 dB nom. Yes Yes Yes

147 x 61 x 46 (mm)
440g

 WTA-2401RTGXI-1000 1 W
(30 dBm)
12 dB nom. Yes Yes Yes
